Top Menu and Plugin Configuration in CM

Plugins can be launched from the Top Menu. These plugins can fulfill tasks from downloading entries (pluginCmExport) to opening RoughCut Edit Project in Adobe Premiere (pluginCmBbPremiereMediaAndGroups). An extensive list of plugins can be found at the bottom of this page.

Create a New Menu Item

Follow these steps to create a new Top Menu item, which launches a desired plugin.

  1. Create a new folder [Menu Item] in the folder  |…|ContentManager|Menu or |…|ContentManager|Menu|...|Children|.
    The new folder name is arbitrary and only defines the location for storing the settings as the name is defined with the label key.
  2. Add the desired keys from the list below.
KeyDescription

Enabled

With the values False/True this menu item can be de-/activated. Default = False

Example: True

Label

Defines the menu item name that is visible in the Top Menu.

Example: Learn David Systems

DisplayIndex

Defines the sorting order of the menu item (low integer numbers come first).

Example: 19998


Optional. Reference to an image in the form of a file path or URL. Reference can be an absolute, relative URL or implicit data:image. The image is displayed left of the menu item.

To add an Font Awesome icon instead, set the value to “icon:” + the name of the icon without its prefixes.

Examples:

  • http:/.../myimage.jpg or
  • /DpeWebApplication/CustomData/myimage.jpg or
  • icon:user

Plugin

The name of the plugin used. Omit this key to define parent menu items with children. See Create Drop Down Menu Items below.

Example: PluginCmOpenLink

Config

Optional. Configuration string, which depends on the plugin (see Available Plugin section below). In the case of PluginCmOpenLink the Config key determines the link which is to be opened.

Example: https://learn.davidsystems.com/

ActionRight

Optional. If you wish to limit the plugin visibility to specific users, you can link the plugin visibility to an existing or newly created Action right. The plugin is then limited to users with this action right.

Example: DpeContentManager.Open

IsVisibleFor0Entries

Optional. Either a configuration string or a boolean allowing to make a plugin visible or not when no entries are selected. False by default.

Example: True

IsVisible

Optional. Configuration string for restricting the visibility of the plugin to specific entries. For more information, see Restricting Visibility of a Plugin to Specific Entries in CM.

Example: not(get('hasAudio'))

RequiredTableRights

Optional. Configuration string that allows the accessibility of plugin to specific tables where the user has configured Table Right.

Default setting requires "Use" right on the table for accessing the plugin. The parameter accepts following values : Use, Read, Create, Delete, Change, Align, SoftDelete(*), NoBroadcast(*). Values in (*) are case sensitive.

Example: Use

For most plugins, an example configuration is delivered with the "PAR_examples" folder inside your DPE software package.

Example: ContentManager_Menu_Fcp.par for the pluginCmBbFcpMediaAndGroups and pluginCmBbFcpProject plugin.


Create Drop Down Menu Items

The configuration of sub-menus follows a similar structure to adding normal Menu Items. The Parent menu item contains the same keys as a normal menu item, except Plugin and Config, plus an and additional folder |Children| which contains all folders for defining the sub-menu items.

Available Plugins

With the growing number of plugins, one can open entries in external applications or start completely customizable workflows, using thepluginCMWorkflowplugin. See a list of available plugins below. Click on the plugin name for a more detailed plugin description and the required config parameter options.

Some plugins, such as the one for FinalCut Pro, requires David Systems' BrowserBridge to be installed. This is primarily because Content Manager cannot call an external application directly for security reasons. For more details please see Installing Browser Bridge. Any additional requirements, such as programs that need to be installed on the client machine or license requirements, are listed in the 'Requirements' column below.

Plugin Name

Description

Requirements
Content Manager basics

pluginCmOpenSce

Opens audio entries in the Subclip Editor (SCE).

SCE license and user rights

pluginCmOpenRceMediaAndGroups

Opens media or groups in RoughCut Edit (RCE).

Available only for groups that belong to the ‘Project’ class.
RCE license and user rights

pluginCmOpenRceProject

Opens video projects in RoughCut Edit.

RCE license and user rights
pluginCmWaveOpens selected entries in Wave.Wave license and user rights
pluginCmCaeOpens one or more entries in Contextual Audio Editor.

pluginCmTransferBroker

Creates TransferBroker tasks.

-

pluginCmWorkflow

Launches workflows which have been supplied with the starting package or been specifically developed for the customer. These customized workflows range from file conversion to posting on Facebook. See link for more information.

-
PluginCmEnps

Adds selected entries into an Electronic Newsroom Production System (ENPS) story bin

DPE BrowserBridge

ENPS

pluginCmBbMte

Opens audio entries or MTE projects in SingleTrack Editor (STE), EasyTrack Editor (ETE) or MultiTrack Editor (MTE).

DPE BrowserBridge

STE, ETE or MTE installation

pluginCmExportDownloads entire entry as a .zip file, or only main media file to the local machine.-

pluginCmBbDigAIRange

Send entries (not groups or stories) to DigAIRange. Config parameter is unused.

DPE BrowserBridge

DigAIRange

Content Manager Option: HiRes Video Preview

pluginCmBbMclPlayer

Opens high-res video in MediaComponent Library (MCL) player. Config parameter is unused.

DPE BrowserBridge

MclPlayerControl setup

Endpoint Manager Final Cut Pro 7

pluginCmBbFcpMediaAndGroups

Opens media or ‘Project’ group entries in FinalCut Pro (FCP).

DPE BrowserBridge

FinalCut Pro

pluginCmBbFcpProject

Opens a video project in FinalCut Pro.

DPE BrowserBridge

FinalCut Pro

Endpoint Manager Adobe Premiere Pro (any version, Windows & Mac OS X)

pluginCmBbPremiereMediaAndGroups

Opens media or 'Project’ group entries in Adobe Premiere Pro.

DPE BrowserBridge

Adobe Premiere Pro

pluginCmBbPremiereProject

Opens a video project in Adobe Premiere Pro.

DPE BrowserBridge

Adobe Premiere Pro
